Discover the new veloheld.iconX.A gravel bike that takes you further – over dusty gravel paths, through dense forests or right through the city. The new Marrakesh Brown colour captures the mood of distant horizons: warm, earthy and timeless.The newly developed steel frame is manufactured in Europe and combines precision with durability. With UDH dropouts, a sturdy T47 bottom bracket and even the option of a light cable guide for a saddle clamp rear light, the veloheld.iconX is ready for your adventures that last longer than daylight hours.

In the wild!

Flo is 1.75 m tall and rides with an inside leg length of 81 cm, frame height M.

Highlights

UDH is on board!

Built for the future – the frame has been completely redesigned! A new detail – the UDH derailleur hanger!

Let there be light!

Saddle clamp reflector with integrated cable routing through the seat and chain stays possible

Details

Frame

Double-butted tubes made of veloheld.CrMo steel, TIG welded, 46 mm head tube, Di2 ready, flat mount disc brake mount for 160 mm brake discs located in the rear frame triangle
Shift (for single-speed drivetrains) and brake cable routing integrated into the down tube; for double-speed drivetrains, one cable must be routed under the down tube
No cable stop on the frame for front derailleurs (not compatible with mechanical double Campagnolo and SRAM groupsets)
Eyelets for mudguards and/or luggage rack
Stainless steel dropouts with replaceable UDH derailleur hanger and hidden kickstand mount
Eyelets integrated into the seat tube for internal cable routing for a saddle clamp rear light
Eyelets for 3 bottle holders and top tube bag

Thru axle

Frame: Axle length: 166 mm; thread length 15 mm; pitch M12x1.0

Fork

veloheld steel fork made of double-butted CrMo steel, 1 1/8″ – 1 1/2″ head tube, flat mount disc brake mount for 140 or 160 mm disc, mounting eyelets for attaching your luggage using “triple cages” or a front luggage rack (“lowrider rack”), mudguard mounting and internal light cable routing possible, installation dimensions: 12×100 mm incl. thru axle, max. load capacity: 5 kg per fork side

veloheld carbon fork with tapered head tube, side “triple cage” eyelets for mounting your lightweight luggage (max. load capacity: 3 kg per fork side), flat mount disc brake mount for 140 or 160 mm disc, mounting eyelets for mudguard, internal brake and light cable routing, mounting dimensions: 12×100 mm incl. thru axle and expander

Drive and brakes

Bottom bracket

for T47, 68 mm

For disc brakes with 160 mm brake discs front and rear, flat mount brake mounts

Wheels & Tyres

Wheel set

Wheel set mounting dimensions: 12×142 mm rear, 12×100 mm front

Tyres

Max. approx. 50-622 (28″) or 54-584 (27.5″) mm wide tyres (depending on make and rim) possible in frame and steel fork without mudguards

Cockpit

Headset

Includes Acros headset 1 1/8″ ZS44/28.6 top and EC 44/40 headset bottom

Sitting

Seat post

Seat post installation dimension: ø 27.2 mm, incl. saddle clamp made of black anodised aluminium

Miscellaneous

Sizes

XS, S, M, L, XL

Accessories

Mudguards: made of durable aluminium, powder-coated in frame colour, 50 mm wide (Please note that due to the compact geometry, especially with smaller frame sizes, contact with the foot may be possible when turning sharply, depending on the pedal system, shoe size and shoe shape.)

Colors

Serienfarbe

Marrakesh Brown

Custom color

RAL-Classic powder coating in gloss or matt for frame and steel fork, decor in black or silver.

If you would like to have your carbon fork painted in the frame color, please contact us before placing your order.

Powder coating?

What is powder coating and what are our quality guidelines?

Find out more here…

Weight

approx. 2.1 kg (frame height M), approx. 1 kg steel fork, approx. 530 g carbon fork

Classification

Bikes in Category 2 are designed for well-paved paths and ensure constant contact with the ground. These bikes are primarily intended for urban mobility, making them ideal for use in road traffic and on public or authorized paths. This category includes urban bikes, city bikes, trekking bikes, and gravel bikes. The maximum allowable total weight, consisting of the rider, luggage, and bicycle, should not exceed 120 kg. Please note that this maximum weight may be further restricted depending on the usage recommendations of the component manufacturers.

Note

Subject to technical changes, errors and omissions.

Note: Subject to technical changes, errors and omissions.

Frame height	XS	S	M	L	XL
for approx. height in cm	155 – 165	164 – 174	173 – 182	181 – 188	187 – 193
for approx. inside leg length in cm	71 – 77	75 – 80	78 – 85	82 – 88	from 85
A Seat tube length	440	470	510	540	560
B Top tube length	525.5	541.5	563	579	594.5
C Wheelbase	1023	1035	1048	1060	1072
D Head tube length	110	130	150	170	190
E Head angle	70°	70.5°	71°	71.5°	72°
F Seat angle	74°	74°	73.5°	73.5°	73.5°
G Chainstay length	437	437	437	437	437
H Fork offset	50	50	50	50	50
I Bottom bracket drop	79	77	77	77	74
J Stack	543	564	584.5	605	623
K Reach	370	380	390	400	410
Wheel size	27.5" or 28"	27.5" or 28"	27.5" or 28"	27.5" or 28"	27.5" or 28"
Standover height	733	749	783	809	823
Approx. seat height from centre of bottom bracket to top edge of saddle	628 - 681	664 - 708	690 - 752	726 - 779	752 - 812

Show only reviews in EN (0)

Add a review Cancel reply

Urban 50%

Tour 80%

Road 50%

Offroad 60%

Race 80%

How will the bike be delivered to me?

The bike is delivered almost fully assembled and safely packed in a cardboard box by a forwarding agent within Germany. After delivery, you can assemble it ready to ride in a few simple steps and without special tools and go on your first ride straight away. You can find all information on assembly here.

What exactly do I have to install after delivery?

After delivery, you can quickly assemble the bike ready to ride with just a few simple steps and a few tools. To do this, the handlebars and stem must be turned in the direction of travel, the pedals installed and your saddle height adjusted.

Alle genauen Schritte der Montage findest Du in der Aufbauanleitung.

Can I test ride the bike?

If you live near one of our dealers, you can also test ride your dream bike there. Please get in touch with the dealer first to make sure that they have the bike in stock and can prepare it for you if necessary.

Wenn Du das Rad direkt bei uns kaufst, kannst Du es nach Erhalt und Montage bei Dir zu Hause auf trockenem Untergrund direkt Probe fahren. Sollte es Dir wider Erwarten nicht gefallen und/oder passen, holen wir es wieder versandkostenfrei bei Dir ab. Dazu musst Du es nur wieder sicher in den Versandkarton packen und auf die Abholung warten. Achtung: Dies gilt nicht für individuell angefertigte Wunschräder.

Do I have an additional guarantee?

Without limiting the statutory warranty rights, we grant you a total warranty of 5 years from the date of purchase on veloheld frames and veloheld forks. You can find the exact details on our warranty and guarantee page.

Bitte registriere Dein Rad innerhalb von 3 Monaten nach Kauf hier, um die Garantie zu erhalten.

What is the maximum permissible system weight?

The maximum permissible system weight for the veloheld.iconX consisting of bicycle, rider and luggage should not exceed 120 kg for frame sizes XS, S and M and 140 kg for frame sizes L, XL and XXL with steel fork. When used with a carbon fork, the limit for all sizes is 120 kg.

Can I fit a side stand?

Yes, you can mount a KSA 18 kickstand directly on the frame at the left rear dropout.
