from 5.199,00 €
As a bike manufacturer, we build every bike individually for you. Due to the current order and delivery situation, we need 6 - 8 weeks after order confirmation to manufacture and ship available bikes.
The veloheld.farway Pinion Tour is your new touring bike for wonderful tours. Precisely manufactured in our frame construction workshop in Leipzig, it offers a robust and comfortable CrMoly frame, a 12-speed Pinion gearbox in conjunction with the low-maintenance Gates Carbon Drive belt drive and the bright SON lighting system.
With 28-inch wheels and 50 mm wide Schwalbe tires, it offers plenty of comfort and traction on any terrain. Like every veloheld bike, it can be customized and is therefore ready for your adventures on the long tour. Overall, the
veloheld.farway Pinion
perfectly combines robustness, low maintenance and comfort – ideal for explorers without compromise.
The frames are made with love and sweat from butted CrMoly tubes in our frame construction workshop in Leipzig.
The dropouts of the wheel were printed from stainless steel powder to the veloheld.farway Pinion dropouts.
Series color too boring? Tell us your desired color and we will coat your individual veloheld.farway Pinion touring bike!
In order to efficiently transfer the enormous torque of the Pinion gearbox to the rear wheel via the Gates belt, the drive is tensioned directly behind the front pulley - the most stable solution for a rigid frame
The Pinion gearbox - twelve extremely low-maintenance and practically wear-free gears with fine gradations for an outstanding gear range and unique shifting comfort. With a total gear ratio of 600 %, it is the perfect shifting system for long, carefree tours.
The complete SON lighting system guarantees perfect illumination of your route and excellent visibility in traffic. The system is completely "Made in Germany" and comes with a 5-year guarantee.
The frame is completely <em>"Made in Germany"</em>. Welded in our frame construction workshop in Leipzig from butted 25CrMo4 tubes and 3D printed stainless steel dropouts and then powder-coated directly in Dresden.
double end-reinforced tubes made of 4130 CrMoly (25CrMo4) steel, TIG-welded, stable 44 mm head tube, stainless steel thru-axle dropouts with internal flat-mount disc brake mount and preparation for KSA 18 kickstand mount (with adapter), frame lock on dropout for Gates Carbon Drive, brake cable routed in down tube, external Pinion gear cable, 3 bottle cage mounts, eyelets on the top tube for the fixed mounting of a small bag
veloheld chromoly rigid fork, 4130 ChrMoly steel, 12×100 mm installation width, extra stable 1 1/8″ – 1.5″ tapered steerer tube, installation height 420 mm, 50 mm fork travel, side “triple cage” eyelets for mounting your luggage or lowrider luggage rack, flat-mount disc brake mount for max. 160 mm disk size
Pinion C1.12 gearshift
The C1.12 gearbox is the manual gearbox for everyday, leisure and touring riders. 12 finely graduated gears offer an outstanding range of ratios and unique shifting comfort. With a total gear ratio of 600 %, the C1.12 gearbox beats modern derailleur gears by far.
Gates CDX belt, 120t
front: 39t Gates Carbon Drive CenterTrack Front Sprocket
Rear: 34t Gates CenterTrack CDX Sprocket, both made of stainless steel for very long service life
(Heavier translation also possible on request)
Pinion Forge 2018, black, 170 mm
Forged crank arms made of lightweight aluminum in a flat design
VP-538
black plastic body, CroMo axle, industrial bearings
Magura MT4
Magura MT4
Magura Storm HC, 160mm brake discs front and rear
Rim: DT G 540 disc, aluminium hollow chamber, 32h, black, rim width 24 mmHub: SON 28 hub dynamo 6V/3W, black (Made in Germany, 5-year guarantee)
Rim: DT G 540 disc, aluminium hollow chamber, 32h, black, rim width 24 mmHub: Pinion singlespeed rear hub H3.R, 32h, black
Schwalbe G-One Overland, 50-622/28-2.00
veloheld.stem – black, 80 mm (S), 90 mm (M, L), 100 mm (XL)
veloheld riser bar – black, 720 mm width, ø 31.8 mm, 20 mm height, 10° rearward bend (backsweep), veloheld grips
or
SQlab 30X, black, 720 mm width, ø 31.8 mm, medium = 30 mm height, 12° backsweep with SQlab grip 710 short in S, M or L
Acros AZX-245, flat, black, ZS44/28.6, EC44/40
SON Edelux II front and SON rear light with parking light function, black/silver
Tubus Logo Evo, black, suitable for 26 kg luggage (support via hidden strut under the mudguard or also with 2 extra struts directly on the frame)
made of durable aluminum, powder-coated in frame color, 60 mm width
“Moonlight Teal” glossy with silver decor
RAL powder coating of your choice in gloss or matt, decor in black or silver
from approx. 14.5 kg
For riding on paved roads, such as asphalt roads and cycle paths, paved forest roads, field paths and hiking trails where there are few or no obstacles such as roots, thresholds, stones and steps. The wheels are in constant contact with the ground or may briefly lose contact with the ground due to minor bumps. This category includes urban and city bikes as well as gravel bikes with racing handlebars. Read more…
Note: Technical changes, errors and omissions excepted.
| Frame size | S | M | L | XL |
|---|---|---|---|---|
| for approx. body height in cm | 165 – 175 | 174 – 184 | 184 – 190 | 189 – 195 |
| for approx. inside leg length in cm | 75 - 80 | 79 - 84 | 83 - 88 | 87 - 93 |
| A Seat tube length | 480 | 510 | 540 | 570 |
| B Top tube length | 574 | 593 | 606 | 623 |
| C Wheelbase | 1087 | 1097 | 1106 | 1117 |
| D Head tube length | 135 | 155 | 175 | 195 |
| E Seat tube angle | 70,5° | 71° | 71,5° | 71,5° |
| F Seat angle | 74° | 73,5° | 73,5° | 73° |
| G Chainstay length | 457 | 457 | 457 | 457 |
| H Fork offset | 50 | 50 | 50 | 50 |
| I approx. bottom bracket drop | 80 | 80 | 80 | 80 |
| J Stack | 600 | 623 | 642 | 661 |
| K Reach | 400 | 408 | 415 | 420 |
| Standover height | 791 | 817 | 841 | 864 |
The bike is delivered almost fully assembled and safely packed in a cardboard box by a forwarding agent within Germany. After delivery, you can assemble it ready to ride in a few simple steps and without special tools and go on your first ride straight away. You can find all information about the structure here.
After delivery, you can quickly assemble the bike ready to ride with just a few simple steps and a few tools.
To do this, the handlebars incl. Turn the stem in the direction of travel, install the pedals and adjust your saddle height.
You will find all the exact assembly steps in the assembly instructions.
If you live near one of our dealers, you can also test ride your dream bike there. Please get in touch with the dealer first so that he really has the bike in stock and can prepare it for you if necessary.
If you buy the bike directly from us, you can test ride it on a dry surface at home after receiving and assembling it. If, contrary to expectations, you don’t like it and/or it doesn’t fit, we will collect it from you again free of charge. All you have to do is pack it safely back into the shipping box and wait for collection. Please note: This does not apply to customized bikes.
Without limiting the statutory warranty rights, we grant you a total warranty of 5 years from the date of purchase on veloheld frames and veloheld forks. You can find the exact details on our warranty and guarantee page.
Please register your bike here within 3 months of purchase to receive the warranty.
The maximum permissible system weight for the veloheld.farway Pinion consisting of bicycle, rider and luggage should not exceed 140 kg for all frame sizes.
Yes, you can mount a KSA18 kickstand on the left dropout using an adapter. You can order it during the ordering process and we will fit it to the bike before shipping.
Send us your question via the contact form or use our other contact options and we will answer your questions.
Send us a message with your desired bike components or give us a call on +49 (0)351 212 952 95 and we will soon build you your ultimate veloheld dream bike!
