veloheld.path frameset

849,00 €

Base price plus Possible options and shipping + packaging

All prices incl. VAT. The actual VAT is calculated based on the delivery address and displayed in the checkout.

  • simply robust – the perfect commuter/touring bike for self-assembly
  • Compatible with Gates belt drive with in-hub gears or also derailleur gears
  • Select here your size and fitment options →

Delivery time

As a bicycle manufacturer, we coat each frameset individually for you. Due to the current order and delivery situation, we need 1 - 2 months after order confirmation to manufacture and ship your frame set.

You are unsure which size is the right one? Have a look at the geometry or let us advise you personally.
Would you like a Prismatic Powders special color? Please contact us in advance by e-mail.
Please also note our Notes on powder coating.

Grand total
Ich habe noch Fragen und wünsche eine persönliche BeratungSchon ab 0% finanzieren

The veloheld.path frame set is ideal for anyone who wants to build their own urban bike a9> urban bike themselves – robust, comfortable and stylish. Cobblestones, potholes and gravel paths are no match for the steel frame handles with ease thanks to 27.5-inch wheels and up to 50 mm tyre width with ease.

This frame set made from high-quality CrMo steel can be fitted with your choice of either belt drive and in-hub gears or classically with derailleur gears equip – entirely depending on your intended use. Of course is the veloheld.path available from us also directly as ready-to-ride urban bike available.

In the wild!

At 1.82 m tall and 84 cm inside leg length, Paul rides a size L frame

Highlights

Round thing!

Eccentric bottom bracket housing for efficient tensioning of the belt or chain when used with a hub gear or as a singlespeed bike.

With or without…

...derailleur hanger for hub or derailleur gears in stainless steel dropout.

Details

Frame

double end-reinforced tubes made of 4130 CroMoly steel, TIG-welded, EBB eccentric bottom bracket housing for tensioning the belt, stainless steel dropouts with internal disc brake mount and KSA 18 side stand mount, Rohloff compatible with OEM2 torque support, anti-rust “ED-Black” coating, external cable routing on the down tube, 3 bottle cages possible, stops for normal derailleur gears available

Fork

4130 CroMoly steel fork, 1 1/8″ – 1 1/2″ head tube, installation height 405 mm, internally routed light cable

Drive

Gear hub

without, installation width: 135 mm rear, 100 mm front

Belt

without

Pinion or pulley

without

Cranks

without

Inner bearing

without, BSA 68 mm width

Pedals

without

Brakes

Brake lever

without

Brake body

without

Brake disk

for disc brakes with max. ø 160mm rear and front brake disks max. ø 180 mm, IS2000 brake mount

Wheels & tires

Wheelsets

without

Tyres

with mudguards max 50-584 width mobile

Cockpit

Stem

without, our recommendation 80 mm length for size S, 90 mm for M and L and 100 mm for size XL

Handlebars

without

Headset

Acros AZX-245, flat, black, ZS44/28.6, EC44/40

Sitting

Saddle

without

Seat post

without, ø 27.2 mm diameter

Miscellaneous

Lighting

without

Luggage carrier

without

mudguards

made of durable aluminum, powder-coated in frame color, 58 mm width (also available without)

Colors

Series color

“Bronze Chrome” gloss with gold decal

Custom color

RAL powder coating of your choice in gloss or matt, decor in black or silver

Powder coating?

What is powder coating and what are our quality guidelines?

Find out more here…

Weight

from 2.2 kg with eccentric bottom bracket housing, fork approx. 1.3 kg

Classification

For riding on paved roads, such as asphalt roads and cycle paths, paved forest roads, field paths and hiking trails where there are few or no obstacles such as roots, thresholds, stones and steps. The wheels are in constant contact with the ground or may briefly lose contact with the ground due to minor bumps. This category includes urban and city bikes as well as gravel bikes with racing handlebars. Read more…

Note: Technical changes, errors and omissions excepted.

Add a review

City 90%
Tour 90%
Road 75%
Terrain 50%

Who is the veloheld.path frameset suitable for

The frameset is aimed at anyone who wants to customize a robust, low-maintenance urban bike or commuter bike with a steel frame.

Which gear types are compatible?

You can use the frameset with hub gears (e.g. Shimano Alfine or Rohloff) or classic derailleur gears.



Is a belt drive possible?

Yes, the frameset is prepared for the Gates Carbon Drive belt drive – including a separable dropout.



What is the maximum width of the tires?

The frame set offers space for tires up to 50 mm wide (2.0″ inch) on 27.5-inch wheels in conjunction with the mudguards. Without mudguards, there is space for approx. 57 mm wide tires (2.25″ inch).



What material is the frame made of?

The frame is made of high-quality, double-butted CrMo steel with a powder-coated surface.

Is the veloheld.path also available as a complete bike?

Yes, the veloheld.path is also available as a fully assembled urban bike with belt drive.
