veloheld.iconX Tourist complete bike

from 3.249,00 €

Base price plus Possible options and shipping + packaging

All prices incl. VAT. The actual VAT is calculated based on the delivery address and displayed in the checkout.

  • the new veloheld.iconX – we have completely redesigned the frame
  • Fully equipped – including mudguards, BuM lights and tube luggage rack
  • Quickly ready to go: Delivered by a courier service and ready for use in just a few simple steps.

Delivery time

As a bike manufacturer, we build every bike individually for you. Due to the current order and delivery situation, we need 4 - 6 weeks after order confirmation to manufacture and ship available bikes.

Would you like a Prismatic Powders special color? Please contact us in advance by e-mail.
Would you like a Prismatic special colour or wet paint finish? Please contact us in advance by email. Please note here also our notes regarding powder coating.
Choose your veloheld frame decal in black or silver by selecting your desired color. Please note that dark frame colors cannot be realized with black, but only with silver decor.
Choose your clear coat here
Sizes M, L, XL and XXL = Delivery 26 August
You are unsure which size is the right one? Have a look at the geometry or let us advise you personally.
Grand total
I still have questions and would like a personal consultation
Lease your veloheld
Financing from as little as 0%
veloheld.iconX Tourist – dein Touringbike für Alltag & AbenteuerThe veloheld.iconX Tourist is the perfect gravel and touring bike for long rides, commuting and travelling with luggage. With lights, mudguards and a luggage rack, it is fully equipped and ready for any weather.The steel frame, manufactured in Europe, offers comfort, stability and durability – ideal for many kilometres on tarmac and gravel. Thanks to UDH dropouts, T47 bottom bracket and lighting system it is technically up-to-date with the latest technology.In Emerald Green the travel bike proves to be timeless, robust and ready for your next adventure.

In the wild!

Flo is 1.75 m tall and rides with an inside leg length of 81 cm, frame height M.

Highlights

UDH!

Built for the future – the frame has been completely redesigned! A new detail – the UDH derailleur hanger!

veloheld.iconX Touristausstattung

Let there be light!

Optimal illumination of all your routes with Busch+Müller lighting systems

Details

Frame

  • double butted tubes made from veloheld.CrMo steel, TIG-welded, 46mm head tube, Di2 ready, in the rear frame triangle mounted flat-mount disc brake mount for 160 mm brake discs
  • shifting (for 1x gears) and brake cable routing integrated in the down tube, for 2x gears a cable must be routed under the down tube
  • no cable stop on the frame for front derailleur (not compatible with mechanical 2x Campagnolo and SRAM groupsets)
  • Eyelets for mudguards and/or luggage racks
  • Stainless steel dropouts with replaceable UDH derailleur hanger and concealed kickstand mount
  • in the seat tube integrated eyelet for internal routing of the cable for a saddle clamp rear light
  • Threads for 3 bottles and a top tube bag

Thru axle

Frame: Axle length: 166 mm; thread length: 15 mm; pitch: M12x1.0

Fork

veloheld steel fork made from double-butted CrMo steel, 1 1/8″ – 1 1/2″ head tube, flat-mount disc brake mount for 140 or 160 mm discs, mounting eyelets for attaching your luggage using ‘triple cages’ or a front luggage rack (‘lowrider rack’), mudguard mounting and internal light cable routing possible, mounting dimensions: 12×100 mm incl. thru-axle, max. load capacity: 5 kg per fork leg

or

veloheld carbon fork with tapered head tube, side-mounted “Triple-Cage” eyelets for mounting your lightweight luggage (max. load capacity: 3 kg per fork side), flat-mount disc brake mount for 140 or 160 mm disc, mounting eyelets for mudguard, internal brake- and also light cable routing, mounting dimensions: 12×100 mm incl. Thru axle and expander

Drive and brakes

Shimano GRX 610 – 1×12
Shimano GRX 610 – 2×12

Wheels & tires

Wheelsets

DT Swiss G 1800 SPLINE 25 DYNAMO, 24 spokes, 28 mm outer width, tubeless ready, approved for max. 130 kg system weight (rider, luggage and bike)

Tyres

Schwalbe G-ONE Allround, faltbar, Tubeless Easy (Auslieferung mit Schlauch), 40-622, bronze-skin

Tyres up to approx. 50–622 mm (28″) or 54–584 mm (27.5″) in width (depending on the make and rim) can be fitted without mudguards on the frame and fork

Cockpit

Stem

veloheld, black

or

Ritchey WCS C220 84D, Blatte Black

80 mm at frame height (XS, S), 90 mm (M, L), 100 mm (XL, XXL)
6 spacers

Handlebars

veloheld, black

or

Ritchey WCS Butano, Blatte Black, Drop 115mm, Reach 73mm, Drop flare 18°, Backsweep 5°

Width: 400 mm (XS, S), 420 mm (M, L), 440 mm (XL, XXL)

Headset

incl. Acros headset: 1 1/8″ ZS44/28.6 top and EC 44/40 bottom

Sitting

Saddle

veloheld, black

Seat post

veloheld, black, glossy

or

Ritchey WCS Alloy Link, Blatte Black, 350mm, Setback 20mm

Miscellaneous

Lighting

Busch+Müller LUMOTEC IQ-XS N plus front light, black and TOPLIGHT Mini plus rear light with parking light function

Luggage carrier

Vega tube, black, suitable for 15 kg of luggage

mudguards

made of durable aluminum, powder-coated in frame color, 50 mm width

(Please note that due to the compact geometry in particular for smaller frame sizes there is contact with the foot during heavy pedalling depending on the pedal system, shoe size and shoe shape may be possible.)

Colors

Series color

Emerald Green with silver decal

Custom color

RAL-Classic powder coating in gloss or matt for frame and steel fork, decor in black or silver.

If you would like to have your carbon fork painted in the frame color, please contact us before placing your order.

Powder coating?

What is powder coating and what are our quality guidelines?

Find out more here…

Sizes

XS, S, M, L, XL

Weight

Complete bike from approx. 12.4 kg

Classification

Bikes in Category 2 are designed for well-paved paths and ensure constant contact with the ground. These bikes are primarily intended for urban mobility, making them ideal for use in road traffic and on public or authorized paths. This category includes urban bikes, city bikes, trekking bikes, and gravel bikes. The maximum allowable total weight, consisting of the rider, luggage, and bicycle, should not exceed 120 kg. Please note that this maximum weight may be further restricted depending on the usage recommendations of the component manufacturers.

Note

Subject to technical changes, errors and omissions.

Note: Subject to technical changes, errors and omissions.

Rahmenhöhe XS S M L XL XXL
Körpergröße 155–165 164–174 173–182 181–188 187–193 192–198
Innenbeinlänge 71–77 75–80 78–85 82–88 85–92 88–96
Sitzhöhe ab TL (min.) 628 664 690 726 752 778
Sitzhöhe ab TL (max.) 681 708 752 779 812 845
Überstandshöhe 733 749 783 809 823 840
Sitzrohrlänge (A) 440 470 510 540 560 580
Oberrohrlänge (B) 525,5 541,5 563 579 594,5 609,5
Radstand (C) 1023 1035 1048 1060 1072 1084
Steuerrohrlänge (D) 110 130 150 170 190 210
Lenkwinkel (E) 70 70,5 71 71,5 72 72
Sitzwinkel (F) 74 74 73,5 73,5 73,5 73
Kettenstreben (G) 437 437 437 437 437 437
Gabelvorlauf (H) 50 50 50 50 50 50
Tretlagerabsenkung (I) 79 77 77 77 74 74
Stack (J) 543 564 584,5 605 623 638
Reach (K) 370 380 390 400 410 420

Show only reviews in EN ()

Add a review

City 50%
Tour 80%
Road 50%
Terrain 60%
Race 80%

How will the bike be delivered to me?

The bike is delivered almost fully assembled and safely packed in a cardboard box by a forwarding agent within Germany. After delivery, you can assemble it ready to ride in a few simple steps and without special tools and go on your first ride straight away. You can find all information on assembly here.

What exactly do I have to install after delivery?

After delivery, you can quickly assemble the bike ready to ride with just a few simple steps and a few tools. To do this, the handlebars and stem must be turned in the direction of travel, the pedals installed and your saddle height adjusted.

Alle genauen Schritte der Montage findest Du in der Aufbauanleitung.

Can I test ride the bike?

If you live near one of our dealers, you can also test ride your dream bike there. Please get in touch with the dealer first to make sure that they have the bike in stock and can prepare it for you if necessary.

Wenn Du das Rad direkt bei uns kaufst, kannst Du es nach Erhalt und Montage bei Dir zu Hause auf trockenem Untergrund direkt Probe fahren. Sollte es Dir wider Erwarten nicht gefallen und/oder passen, holen wir es wieder versandkostenfrei bei Dir ab. Dazu musst Du es nur wieder sicher in den Versandkarton packen und auf die Abholung warten. Achtung: Dies gilt nicht für individuell angefertigte Wunschräder.

Do I have an additional guarantee?

Without limiting the statutory warranty rights, we grant you a total warranty of 5 years from the date of purchase on veloheld frames and veloheld forks. You can find the exact details on our warranty and guarantee page.

Bitte registriere Dein Rad innerhalb von 3 Monaten nach Kauf hier, um die Garantie zu erhalten.

What is the maximum permissible system weight?

The maximum permissible system weight for the veloheld.iconX consisting of bicycle, rider and luggage should not exceed 120 kg for frame sizes XS, S and M and 140 kg for frame sizes L, XL and XXL with steel fork. When used with a carbon fork, the limit for all sizes is 120 kg.

Can I fit a side stand?

Yes, you can mount a KSA 18 kickstand directly on the frame at the left rear dropout.

My question is not listed here...

Send us your question via the contact form or use our other contact options and we will answer your questions.

    Your custom bike

    Not the right features for you?

    Send us a message with your desired bike components or give us a call on +49 (0)351 212 952 95 and we will soon build you your ultimate veloheld dream bike!
