veloheld.icon Complete bike

From 4.199,00 €

Base price plus Possible options and shipping + packaging

All prices incl. VAT. The actual VAT is calculated based on the delivery address and displayed in the checkout.

(1 customer review)
  • Columbus tubes, welded in Germany: Italian steel tubing, processed in our workshop
  • Your colour, your choice: Any RAL Classic colour, gloss or matt, decals in black or silver. Individually painted in Germany
  • Individually configurable: Shimano or SRAM, DT Swiss wheels in two versions
  • 700C x 40 mm tyre clearance: Because allroad means you decide where the road ends

Delivery time

As a bike manufacturer, we build every bike individually for you. Due to the current order and delivery situation, we need 4 - 6 weeks after order confirmation to manufacture and ship available bikes.

Any RAL Classic colour possible · gloss or matt · decals in black or silver · individually painted in Germany
Please also note our instructions for powder coating.
Choose your veloheld frame decals in black or silver when selecting a custom colour. Please note that dark frame colours can only be combined with silver decals, not black ones.
Here you can go directly to the Geometry of the bike.
Lead times for SRAM groupsets on request
Lead times for ERC 1600 on request
Grand total
Ich habe noch Fragen und wünsche eine persönliche BeratungSchon ab 0% finanzieren
Imagine a bike that accelerates effortlessly on tarmac and lets you breathe easy on gravel.The veloheld.icon is built for exactly that: a steel allroad bike that loves speed and makes comfort tangible – day after day.Made in our frame-building workshop in Leipzig: Italian Columbus Life chromoly tubes, precise 3D-printed stainless steel dropouts – and consistently modern in concept. The icon 2026 Allroad is designed exclusively for electronic groupsets, with fully integrated cable routing and a UDH dropout for a clean cockpit, protected cables and a tidy silhouette.

Pure passion!

The frame is welded from Italian Columbus Life tubes

3D printed!

The dropouts are 3D-printed from stainless steel

Individual!

Tell us your favourite colour and you’ll get your very own veloheld.icon!

In the wild!

Tim is 1.84 m tall and, with an 85 cm inseam, rides frame size M sportily at the upper limit. He would also be a perfect fit for frame size L.

Details

Frame

Triple-butted Columbus Life tubes, TIG-welded, 44 mm head tube, 3D-printed stainless steel dropouts with UDH derailleur hanger, T47 bottom bracket shell, fully integrated cable routing for electronic groupsets, flat-mount disc brake mount inside the rear triangle for 140 or 160 mm rotors, optimised for Shimano Di2 or SRAM AXS drivetrains, mounts for 2 bottle cages, plus 2 eyelets on the top tube for a bag and eyelets for mudguard stays at the bottom of the seat stays.

Fork

veloheld UD full carbon fork painted in frame colour, 1 1/8″ – 1 1/2″ steerer with integrated brake hose routing, 12×100 mm thru axle

Thru axles

Frame: M12x142 mm, axle length 166 mm, thread length 15 mm, pitch 1.0
Fork: M12x100 mm, axle length 125 mm, thread length 14 mm, pitch 1.5 (Maxle)
(both included in the scope of delivery)

Drivetrain and brakes

Shimano 105 Di2 – 2×12
Shimano Ultegra Di2 – 2×12
SRAM Rival AXS – 2×12
SRAM Force AXS – 2×12

Wheels & tyres

Wheelsets

DT Swiss ER 1600 SPLINE 30, 24 spokes, 26 mm outer width, tubeless ready, approved for a max. system weight of 130 kg (rider, luggage and bike)

DT Swiss ERC 1600 45, 24 spokes, 28.5 mm outer width, tubeless ready, approved for a max. system weight of 120 kg (rider, luggage and bike)

Tyres

Schwalbe PRO-ONE Evolution Super Race V-Guard, folding, Tubeless Easy (supplied with inner tubes), 34-622, bronze-skin

Tyres up to 40 mm wide (actual measured width), or up to 38 mm for size S, fit in frame and fork without mudguards

Cockpit

Stem

Ritchey WCS Switch, Black

90 mm for frame size S, 100 mm (M, L), 110 mm (XL)

4x 5 mm spacers

Handlebars

Ritchey WCS Streem Internal Routing Handlebar, drop flare 10°, backsweep 5°

380/420 mm for frame size S, 400/440 mm for frame sizes M and L, and 420/460 mm for XL

Headset

Ritchey WCS Switch External Cup EC Headset

Seating

Seat post

Ritchey WCS Alloy Link, Blatte Black, 350 mm, 20 mm setback
incl. Columbus seat clamp in black anodised aluminium

Saddle

veloheld, black

Colours

Standard colour

“Illusion Merlot” with silver decals (painted in Germany)

Custom colour

RAL colour of your choice in gloss or matt, decals in black or silver

Powder coating?

What is powder coating and what are our quality guidelines?

Find out more here…

Weight

Complete bike from approx. 9 kg (depending on spec and size)

Classification

For riding on paved roads, such as asphalt roads and cycle paths. Both wheels never lose contact with the ground (no jumps, no riding on just one wheel). This category includes road bikes with road bike handlebars. Read more…

Note: Technical changes, errors and omissions excepted.

Rahmenhöhe S M L XL
Körpergröße 163–170 171–178 179–186 187–194
Innenbeinlänge 76–81 80–85 83–88 86–91
Sitzhöhe ab TL (min.) 673 708 726 753
Sitzhöhe ab TL (max.) 704 741 759 787
Überstandshöhe 722 766 791 813
Sitzrohrlänge (A) 480 525 550 575
Oberrohrlänge (B) 531 544 565 591
Radstand (C) 995 1004 1016 1037
Steuerrohrlänge (D) 120 130 150 170
Lenkwinkel (E) 72° 72,5° 73° 73°
Sitzwinkel (F) 74° 74° 73,5° 73°
Kettenstreben (G) 425 425 425 425
Gabelvorlauf (H) 47 47 47 47
Tretlagerabsenkung (I) 75 75 73 73
Stack (J) 551 563 581 600
Reach (K) 373 383 393 408
  • christopherklose08@gmail.com
    DE
    Christopher

    Heute ist mein Veloheld angekommen und ich habe gleich eine Runde damit gedreht. Kann es kaum erwarten eine Tour damit zu machen. Ein grosses Lob und Dankeschön an das ganze Team!

Show only reviews in EN (0)

Add a review

City 30%
Tour 90%
Road 100%
Sport 100%
